2"
Mechanical
Lock Panel
The 2″ Mechanical Lock panel is a time-tested standing seam system known for its strength, weathertight performance, and proven reliability across commercial, industrial, and architectural applications.
Its mechanically seamed design, concealed fastener system, and superior weathertight performance make it a dependable, high-performance choice for demanding roofing applications.
2"
Mechanical
Lock Panel
The 2″ Mechanical Lock panel’s precision seaming and watertight design make it a durable, high-performance solution for roofing demanding commercial, industrial, and architectural projects.
The 2″ Mechanical Lock panel is a high-performance steel system designed to deliver reliability in commercial, industrial, and architectural applications.
2" Mechanical Lock
Panel Information
2" Mech.
Lock Panel
UL Wind Uplift Rated
Certified to meet UL wind uplift standards for dependable performance in high-wind conditions.
Water infiltration
The 2″ Mechanical Lock panel features a tight mechanically seamed, interlocking design that allows for zero water intrusion, making it a reliable choice for low-slope and high-exposure applications where watertight performance is critical.
TREDNING COLORS
24g Color Options
Beige
Berry
Black
Burnished Slate
Charcoal Gray
Copper Metallic
Dark Bronze
Dark Brown
Dark Gray
Dark Red
Forest Green
Galvalume
Ivory
Koko Brown
Light Stone
Rural Red
Rustic Red
Taupe
View more of our color options for the 1.5″ Mechanical Lock and more at our color options page!
Panel Data
2" Mechanical
Lock Panel
The 2″ Mechanical Lock panel is available in multiple gauge and color options, offering flexibility for commercial, industrial, and architectural applications. Designed for low-slope roofs and long panel runs, its 16″ width and strong spanning capability provide reliable performance across demanding projects. With options for fixed or sliding clips to manage structural needs and thermal movement, this system requires a mechanical seamer for installation, delivering a secure, weathertight, and professional finished appearance.
UL - Wind Uplift Rated
A UL wind uplift rating verifies a panel’s ability to resist uplift forces caused by high winds through controlled pressure testing. The 1.5" Mechanical Lock Panel meets UL 580 Class 90, confirming its ability to withstand significant wind loads while maintaining secure attachment and long-term performance.
210A Structural Spanning Capabilities
The Panel 210A "2" Mechanical Lock Panel" is a structural roof system engineered from high-strength 24-gauge steel that achieves a UL 580 Class 90 uplift rating and supports allowable uniform loads exceeding 80 PSF at standard 4-foot spans.
Learn more about the 2″ Mechanical Lock’s installation process and trim details by downloading the full installation manual.
2" Mechanical Lock
GENERAL DATA SHEET
A General Data Sheet is a concise technical overview that highlights a product’s key specifications and performance ratings. For the 2″ Mechanical Lock, it includes panel dimensions, gauge and color options, UL testing data, warranty information, and approved residential and light commercial applications.
